Our Bar Harbor workshop buildings are relatively easy to assemble however if you feel that you may want some assistance check out our hire a contractor page.
Workshops
Bar Harbor
Mother nature friendly, to stand
the test of time.
Our Bar Harbor workshop style was designed with the elements in mind. This tough cookie can more than handle anything that Mother Nature throws at it. The master piece to this cedar workshop design is the salt box roof, shorter in front to catch those sunshine rays and longer at the back to protect it from bad weather. The Bar Harbor workshop can be fitted out with casement windows, storm shutters, and heritage hardware. Space is in no short supply and so anything and everything that you have in mind for your workshop can be accomplished with the Bar Harbor. Make it your own in our Custom Design Center!
overview
-
Designed to withstand the elements our Bar Harbor workshop kit and its unique saltbox roof brings character to any outdoor surrounding. Learn more about pricing and your Bar Harbor workshop kit in these style tabs.
-
![Bar Harbor workshop kit]()
Features
- Characterized by a spacious saltbox. - Plenty of headroom. - Well suited to store all your tools.
Popular options:
- Traditional flower boxes
- Arch windows
- Asphalt shingles
- Storm shutters
- Full length window
- Arch single doors
Floor plans
Below are a few sample Bar Harbor workshop floorplans to get you started.For more ideas and photos please visit Interiors under inspiration.
Bar Harbor floor plan configurations
Try this Floor Planner Tool to design your own space and share as you like. You may also download graph paper and print out a few sheets to help designing your own space!
Available Bar Harbor workshop kit sizes
Bar Harbors have sizes ranging from 24 sq.ft to 144 sq.ft
If you cannot find your size please contact us.
Assembly
Level of Difficulty:
Like all of our buildings, our Bar Harbor home workshop includes easy-to-follow instructions, diagrams, and assembly videos that will help you through the process.
Below is a series of photos showing one of our Bar Harbor buildings being assembled.
-
Sub-floor installation for a Bar Harbor
-
![Bar Harbor workshop wall frame install]()
Bar Harbor workshop wall frame install
-
![Finished Bar Harbor workshop]()
Finished Bar Harbor workshop (click image for more details)
-
3D Video Tour of a Bar Harbor building
The product featured is a Bar Harbor workshop kit in a poolside setting with the following options: Opening windows, standard single door, a screen kit.
Visit our 3D Tours page to see all the Summerwood Styles.
-
Bar harbour workshop video tour
details & specs
Bar Harbor Workshop Kit Dimensions
| A | B | C | D | E |
|---|---|---|---|---|
| BUILDING DEPTH | BUILDING HEIGHT | FLOOR HEIGHT | WALL HEIGHT | ROOF HEIGHT |
| 4' | 8' - 4 1/8" | 5 5/8" | 6' - 4 1/2" | 1' 6" |
| 6' | 8' - 11 1/2" | 5 5/8" | 6' - 4 1/2" | 2' - 1 3/8" |
| 8' | 10' - 2 3/8" | 7 5/8" | 6' - 10 1/2" | 2' - 8 1/4" |
| 10' | 10' - 9 3/8" | 7 5/8" | 6' - 10 1/2" | 3' - 3 1/4" |
| 12' | 11' - 4 1/4" | 7 5/8" | 6' - 10 1/2" | 3' - 10 1/8" |
| 14' | 11' - 11 1/4" | 7 5/8" | 6' - 10 1/2" | 4' - 5 1/8" |
| 16' | 12' - 8 1/4" | 8 3/8" | 6' - 10 1/2" | 5' - 1/8" |
| 18' | 13' - 3 1/2" | 8 3/8" | 6' - 10 1/2" | 5' - 7 3/8" |
| 20' | 13' - 10 3/8" | 8 3/8" | 6' - 10 1/2" | 6' - 2 1/4" |
| 22' | 14' - 5 3/8" | 8 3/8" | 6' - 10 1/2" | 6' - 9 1/4" |
| 24' | 15' - 3/8" | 8 3/8" | 6' - 10 1/2" | 7' - 4 1/4" |
| 26' | 15' - 7 1/4" | 8 3/8" | 6' - 10 1/2" | 7' - 11 1/4" |
| 28' | 16' - 2 1/4" | 8 3/8" | 6' - 10 1/2" | 8' - 6 1/8" |
Our measurements (i.e. 8ft. x 12ft.) are taken from the outside of the floor & wall framing, therefore, they don't include the siding, and/or sheathing.
For true interior measurements, subtract the thickness of the wall framing; 3 ½” for 2x4 walls, and 5 ½” for 2x6 walls. Note: 2 x 4 is actually 1 ½” x 3 ½” and 2 x 6 is actually 1 ½” x 5 ½” due to the properties of "finished” lumber.
Wall Plan
Wall plan drawing for a Bar Harbor building
For true exterior dimensions, add the siding, sheathing (if applicable), and corner trim pieces. The Canexel siding is 3/8" thick, the cedar siding is 3/4" thick and the log siding is 1 1/2" thick. The wall sheathing varies from 7/16” to 3/4”. The corner trim is 3/4".
If you have any other questions pertaining to the size of the building, please do not hesitate to ask us, we're here to help.
Roof Framing Plan
In strong competition with hip roofing, gable roofing is up there for the most popular roofing style. Common in Bar Harbor shed designs are gable roofs, which typically features a continuous ridge, with two sides sloping from the center toward the walls of the structure.
Gable roofs are much easier to frame, sheath, and finish, giving the vertical wall component of a gable roof its style, known as “gable ends”.
Ventilation is easy to install. Due to its geometry and access to gable ends, roof vents can be placed on the gable ends rather than the roof itself. Consult with your contractor or roofing company, for the most effective ventilation system for your roof.
Roof framing drawing for a Bar Harbor building
Overhang Detail
Soffits are the cedar trim pieces that are attached to the underside of the rafter ends. Fascia is typically the cedar 1x4 that’s used to cover the rafter tips and provide a nice straight level line for the bottom of your roof.
Bar Harbor shed overhang detail
Foundation
The Bar Harbor workshop is well suited for a traditional patio stone foundation. A concrete pad is also ideal for poolside applications.
Visit Foundations Page for detail.
Bar Harbor building foundation
Materials
Like all summerwood designs, the Bar Harbor workshop kit is a fantastic display of premium grade materials coming together for any of your outdoor needs. Our materials are chosen for their aesthetic appeal, durability, and environmental friendliness. Construction is engineered for garages and cabins but ideally suited for storage sheds and pool cabanas as well.
| item | material | dimension | notes |
|---|---|---|---|
| runners | pressure treated | 2x6 | underside of floor framing |
| joists | pressure treated | 2x4 - 2x8 | 16" on center |
| sheathing | spruce | 48" x 96" x 5/8" | tongue & groove |
| material upgrades | |||
| floor insulation | expanded polystyrene | 3 1/2" & 5 1/2" | within floor cavities |
| pine flooring | white pine | 1x6 | tongue & groove |
| item | material | dimension | notes |
|---|---|---|---|
| wall plates | spruce | 2x4 - 2x6 | bottom, top, double top |
| wall studs | spruce | 2x4 - 2x6 | 16" on center |
| siding | cedar channel | 1x8 | standard horizontal siding |
| material upgrades | |||
| canexel siding | canexel | 1x8 | studs & plates |
| cedar wall framing | cedar | 2x8 - 2x6 | studs & plates |
| esu1a | osb + typar | n/a | wall sheathing & building wrap |
| wall insulation | expanded polystyrene | 3 1/2" & 5 1/2" | within wall cavities |
| item | material | dimension | notes |
|---|---|---|---|
| ceiling | spruce | 2x4 - 2x10 | ceiling framing |
| rafters | spruce | 2x4 - 2x10 | 24" on center maximum |
| ridge board | spruce | 2x4 - 2x10 | n/a |
| sheathing | osb | 48" x 96" x 7/16" | n/a |
| material upgrades | |||
| cedar roof boards | cedar | 1x6 - 1x8 | n/a |
| cedar rafters | cedar | 2x6 - 2x12 | n/a |
| roof insulation | expanded polystyrene | 3 1/2" & 5 1/2" | on roof surface |
| item | material | dimension | notes |
|---|---|---|---|
| cedar trim | cedar | 1x6 - 1x8 | corners, soffit, fascia |
| material upgrades | |||
| maintenance free trim | versatex | 1x4 - 1x8 | corners, soffit, fascia |
Popular upgrades
Enhanced Siding Package
If you are thinking of adding insulation, consider adding one of our "enhanced siding packages". It's a layer of sheathing (OSB or plywood) and house wrap (Typar and optional HomeSlicker) that provides a moisture barrier to your structure.
Enhanced siding package upgrade
Interior Cedar Siding and Framing
The Bar Harbor style allows for a wide array of interior finishes. Our cedar siding or framing interior upgrade can be incorporated on the walls and/or ceiling, providing a warm rustic feel.
Interior cedar siding choices for a Bar Harbor workshop
Finishing
Once your Bar Harbor garden shed building is complete, there are a few things you can do on the inside to add to the comfort and enjoyment of your new Summerwood Bar Harbor.
Please see Interior Finishing under Advice for more information
Insulation
Enjoy your Summerwood Bar Harbor in any season and remain comfortable by implementing insulation in the floor, walls, and/or roof.
Insulation for a Bar Harbor building
Electrical
The inside of our Bar Harbor home workshop are deliberately left exposed to accommodate various electrical applications.
Electrical configuration option
Plumbing
Often the Bar Harbor style is required to accommodate change rooms, bathroom or bar sinks.
Plumbing for a Bar Harbor workshop
pricing
Visit "options and accessories" for detail and pricing of our accessories.
Find below pricing for all of the Bar Harbor sizes that we have built so far. Don't see your size? Ask us and we will provide you with a quote.
Note that pricing below is for the base kit only. Doors, windows, and other options are à la cart so that you can customize to your hearts content.
Custom Designs
Summerwood will take your custom design and make it your own. If you have something different in mind, talk to one of our designers about bringing it to life.
get a professional involved
Our seasoned designers would love to help you find your ideal design.
We're just a phone call away.
