Bellevue

An ornate design that elevates any setting.

The Bellevue is truly a sight to behold. With its airy two tiered roof, this design makes any setting a view unto itself. Whether overlooking a lakefront or a meticulously landscaped back yard, the Bellevue will quickly become one of your favourite places for quiet contemplation and conversation with loved ones.

Swipe or tap photos Swipe to browse photos or tap for pricing/details.

overview

  
    
  • The Bellevue pavilion turns any space into a destination, perfect for sunny afternoons with company. Find out more about the Bellevue pavilions and pricing in the style tabs above.

  • Bellevue garden gazebo

Features

- Characterized by a square hip roof.
- Beautiful open air design
- The perfect spot for backyard parties

Popular options:
  • Classic Screen Kits
  • Wall Benches
  • Weathervanes

Available Bellevue garden gazebo sizes

Bellevue gazebos have sizes ranging from 64 sq.ft to 196 sq.ft

If you cannot find your sizes, please contact us.

Assembly

Level of Difficulty:

Though the Bellevue garden gazebo building requires some carpentry skills, it’s a great DIY construction project. Our gazebo kits include easy-to-follow instructions, diagrams, and assembly videos that will help you through the process.

Below is a series of photos showing one of our Bellevue being assembled.

  • Bellevue Gazebo frame install

  • Bellevue Gazebo roof install

  • Bellevue Gazebo two-tiered roof assembly

  • Bellevue Gazebo roof interior

  • Bellevue Gazebo completed with two-tiered roof

Hiring a contractor

The Bellevue style is manageable to assemble with a couple of extra set of hands, however, if you feel that you may want some assistance check out ourhire a contractor page.

Building a Champlain gazebo
  

details & specs

  
    

Bellevue Garden Gazebo Dimensions

BELLEVUE GENERAL SPECIFICATIONS CHART
A B C D E
BUILDING SIZE BUILDING HEIGHT FLOOR HEIGHT WALL HEIGHT ROOF HEIGHT
NOMINAL ACTUAL
8' 8' - 3 1/16" 12' - 1" 5" 7' - 5" 4- 9"
10' 10' - 1 5/8" 13' - 2.5" 5" 7' - 5" 5' - 4 1/2 "
12' 12' - 1/2" 13' - 10.5" 5" 7' - 5" 6' - 1/2"
14' 13' - 11 3/16" 14' - 4.5" 5" 7' - 5" 6' - 6 1/2"
16' 15' - 8 15/16" 16' - 1.5" 7" 7' - 6" 8' - 1/2"
18' 17' - 8 15/16" 18' - 6 1/4" 7" 8' - 11 1/2" 8' 11 3/4"
20' 19' - 8 15/16" 19' - 5" 7" 8' - 11 1/2" 9' - 11"

Our measurements (i.e. Nominal & Actual Building Size) are taken from the outside face of the upright columns. In the figure above it is represented in measurement “A”, it is portrayed in plan view in the “Floor Framing” section further down on this page.

Wall Assembly

Bellevue gazebo wall assembly drawings

All our gazebo styles feature built-up columns comprised of upright posts sandwiched by wall sides on either side. The Bellevue gazebo wall sides come with spandrels and railings, and are designed to have screen kits added and wall benches mounted.

If you have any other questions pertaining to the size of the building, please do not hesitate to ask us, we're here to help.

Roof Assembly

The Bellevue garden gazebo roof increases in complexity as the size increases, below is the roof framing for the Bellevue. For smaller sizes, the size and number of components incorporated in the roof structure are reduced.

Bellevue roof assembly drawing

Floor Framing

Bellevue’s Summerwood gazebo floors are built with pressure treat framing. However, most Bellevue structures are assembled on existing floor platforms, like patio floors, so you can choose to omit the floor section altogether.

Floor frame drawing for a Bellevue gazebo

Foundations

The Bellevue style is well suited for a traditional patio stone foundation. A concrete pad foundation or pier footings are also possibilities.

Visit Foundations page for detail.

Framed garden gazebo floor sections

Materials

Like all Summerwood gazebos, the Bellevue is a fantastic display of premium materials coming together for any of your backyard needs.

Floor
item material dimension notes
joists presure treated 2x4 - 2x6 framed triangular sections
skirt cedar 1x4 - 1x6 covers pt material
floor boards cedar 2x6 nailed to cleats to form panels
floor splines cedar 2x2 floor members separating panels
floor center cedar 2x8 center floor component
Walls
item material dimension notes
uprights cedar 2x4 - 2x6 centre of supporting column
wall sides cedar 2x6 - 2x8 fastend to either side of upright
wall jambs cedar 2x4 - 2x6 fastend to wall sides
rails cedar 2x3 - 2x4 N/A
wall panels cedar 2x4 & 1x6 N/A
pickets cedar 2x2 N/A
Roof
item material dimension notes
rafters cedar 2x8 - 2x12 roof framing members
compression ring cedar 2x8 - 2x12 center framing for cupola
roof boards cedar 1x6 roof substructure
shingles cedar n/a outter skin of the roof
cap & bead cedar n/a trim along roof ridges
Cupola
item material dimension notes
rafters cedar 2x4 - 2x6 roof framing members
hub cedar 4x4 center framing for cupola
roof boards cedar 1x6 roof substructure
shingles cedar n/a outter skin of the roof
cap & bead cedar n/a trim along roof ridges
cone cedar 2x8 top trim element for the peak

Mix & Match

Like all summerwood styles if you wish to customize your building further you have the option to combine design elements/ building features from one gazebo to another.

  

pricing

  

Visit "options and accessories" for detail and pricing of our accessories.

Find below pricing for all of the Bellevue sizes that we have built so far. Don't see your size? Ask us and we will provide you with a quote.

    

XLG Bellevue
Gazebos ( >130 sq.ft.)

All prices in $USD
Medium Bellevue
Gazebos, price list
kit size pre-cut
12ft.x12ft. $14,195 $14,195
14ft.x14ft. $19,895 $19,895

Custom Designs

Summerwood will take your custom design and make it your own. If you have something different in mind, talk to one of our designers about bringing it to life.

  

let us help build your dream

Our seasoned designers would love to help you find your ideal design.
We're just a phone call away.
